Product Details
Place of Origin: CHENGDU, CHINA
Brand Name: HUIYUAN
Certification: ISO9001
Model Number: GCYFTY-60G652D
Payment & Shipping Terms
Minimum Order Quantity: 4KM
Price: Negotiable
Packaging Details: Wooden drum
Delivery Time: 5 to 20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000km/month
Product Name: |
60F G.G652D Micro Fiber Optic Cable Air Blown Optic Cable A-D(ZN)2Y/4Y / A-DQ(ZN)2Y |
Fiber Count: |
60F |
Fiber Type: |
G.652D |
Diameter (±0.2mm): |
5.6mm±0.2mm |
Outer Jacket: |
High Density Polyethylene |
Application: |
FTTX |
Microduct To Blow: |
10/8mm |
Blowing Distance: |
1000 Meter |
Product Name: |
60F G.G652D Micro Fiber Optic Cable Air Blown Optic Cable A-D(ZN)2Y/4Y / A-DQ(ZN)2Y |
Fiber Count: |
60F |
Fiber Type: |
G.652D |
Diameter (±0.2mm): |
5.6mm±0.2mm |
Outer Jacket: |
High Density Polyethylene |
Application: |
FTTX |
Microduct To Blow: |
10/8mm |
Blowing Distance: |
1000 Meter |
60F G.G652D Micro Fiber Optic Cable Air Blown Optic Cable A-D(ZN)2Y/4Y / A-DQ(ZN)2Y
Description
Huiyuan's air blown micro cables are designed with small diameter and light weight. it has below characteristics:
1. Non-metal design to prevent the cable from radio interference and magnetic wave interference.
2. Specially designed compact structure to prevent loose tubes from shrinking
3. Loose tube filling compound ensure good moisture resistance performance
4. Good flexibility
5. High density fiber packed
6. Small diameter and light weight
7. High blowing performance
Technical specification:
| P/N | GCYFY-60 | |
| Fibre Count | 60 | |
| Number of loose tube | 5 | |
| Number of filled string | 1 | |
| Number of fiber/tube | 12 | |
| Overall Diameter | 5.6±0.2 mm | |
| Weight | 27 kg/km | |
| Min. Bending radius - Static | 12*Cable diameter | |
| Min. Bending radius - Dynamic | 20*cable diameter | |
| Cable Fiber Attenuation (single mode) | 0.35dB/km max @1310nm 0.22dB/km max @1550nm | |
| Temperature range | Storage -40 to +70℃, Installation -10 to +40℃, Operation -40 to +70℃ | |
| Cable service life (estimate value) | 25 years | |
Fiber specification:
| Single mode fiber | 9/125um OS2 G.652D |
| Chromatic dispersion | |
| @1285-1330nm ps/(nm.km) | ≤3.5 |
| @1550nm ps/(nm.km) | ≤1.8 |
| Attenuation - cable | |
| Max. @1310nm (dB/km) | 0.35 |
| Max. @1550nm (dB/km) | 0.24 |
| Max. @1625nm (dB/km) | 0.26 |
| Cable cut-off wavelength (λcc) (um) | ≤1260 |
| Mode field diameter | |
| @1310nm (um) | 9.2±0.4 |
| @1550nm (um) | 10.4±0.5 |
| Zero dispersion wavelength (λ0) (nm) | 1302-1322 |
| Group refractive index | |
| @1310nm | 1.467 |
| @1550nm | 1.468 |
Cable structure:
1. Ripcord 2. Loose tube 3. FRP 4. Jelly 5. Water blocking yarn 6. Fiber
Standard drum length
2000m/drum, 4000m/drum & 6000m/drum
Fiber color
| Fiber No.1 = Blue |
| Fiber No.2 = Orange |
| Fiber No.3 = Green |
| Fiber No.4 = Brown |
| Fiber No.5 = Slate |
| Fiber No.6 = White |
| Fiber No.7 = Red |
| Fiber No.8 = Black |
| Fiber No.9 = Yellow |
| Fiber No.10 = Violet |
| Fiber No.11 = Rose |
| Fiber No.12 = Aqua |
Loose tube color
| Loose tube No.1 = Blue |
| Loose tube No.2 = Orange |
| Loose tube No.3 = Green |
| Loose tube No.4 = Brown |
| Loose tube No.5 = Slate |
Cable text print: (Support customized text)
HYOC GCYFTY 60 G652D [Drum No.] [Month-Year] [Meter marking]
Order information
| Number of fibres | Fibre class | Part name |
| 60 | G657A1 | GCYFTY 5X12 G657A1 5.60MM |
| 60 | G652D | GCYFTY 5X12 G652D 5.60MM |
| 60 | OM1 | GCYFTY 5X12 OM1 5.60MM |
| 60 | OM2 | GCYFTY 5X12 OM2 5.60MM |
| 60 | OM3 | GCYFTY 5X12 OM3 5.60MM |
| 60 | OM4 | GCYFTY 5X12 OM4 5.60MM |
