Product Details
Place of Origin: CHENGDU, CHINA
Brand Name: HUIYUAN
Certification: ISO9001
Model Number: EPFU-6G652D-PE
Payment & Shipping Terms
Minimum Order Quantity: 10KM
Price: Negotiable
Packaging Details: Wooden drum
Delivery Time: 5 to 20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5000km/month
Product Name: |
Air Blown Fiber Optic Cable FTTx 6 G652D EPFU Singlemode Blown Fiber Optic |
Fiber Count: |
6F |
Fiber Class: |
G652D |
Fibre Type: |
Singlemode |
Cable Diameter: |
1.35mm |
Sheath Colour: |
Yellow |
Cable Metal-free: |
Yes |
Type Of Installation: |
Microduct |
Product Name: |
Air Blown Fiber Optic Cable FTTx 6 G652D EPFU Singlemode Blown Fiber Optic |
Fiber Count: |
6F |
Fiber Class: |
G652D |
Fibre Type: |
Singlemode |
Cable Diameter: |
1.35mm |
Sheath Colour: |
Yellow |
Cable Metal-free: |
Yes |
Type Of Installation: |
Microduct |
Air Blown Fiber Optic Cable FTTx 6 G652D EPFU Singlemode Blown Fiber Optic
Description
EPFU 6V 9/125 SM G657A1 Fiber Unit (FU) with 6 fibers in an encapsulation layer providing excellent dimensional and thermal stability. An outer HDPE layer provides a high level of protection and excellent installation properties. The FU is designed for blowing into microducts and tube bundles. The fibres are dry, not coated with gel, thus permitting fast and contamination –free connections.
Technical specification:
| Items | Specification | |
| Optical fiber | G652D | |
| Fibre type | Singlemode | |
| Number of fiber | 6 fibre | |
| Outer sheath material | HDPE | |
| Cable nominal diameter (±0.05mm) | 1.35mm | |
| Cable approx. weight (kg/km) | 1.2 | |
| Temperature range | Installation | -10 to +40 |
| Storage | -20 to +60 | |
| Operation | -20 to +60 | |
| Air Blowing | Equipment: PR140, Duct: 5/3.5mm, Blowing pressure: ≤10bar, Typical blowing length: 1000m |
|
| Applicable microduct | LSZH 5/3.5mm | |
Blowing test:
| Fiber Count | 6F |
| Test equipment | PLUMETTAZ UM25; ERICSSON F; CATWAY FBT-1.1 |
| Standard duct | 5.0/3.5 mm |
| Air pressure | 7bar / 10bar |
| Typical blowing distance | 500m / 1000 m |
| Typical blowing time | 12 min / 18 min |
Fiber specification:
| Characteristics | Specified Values | Units | |
| Mode field diameter | at 1310nm | 9.2±0.4 | µm |
| at 1550nm | 10.4 ± 0.6 | mm | |
| Attenuation coefficient | at 1310nm | ≤0.40 | dB/km |
| at 1550nm | ≤0.30 | dB/km | |
| Cladding diameter | 125.0±1.0 | µm | |
| Cladding non-circularity | ≤1.0 | % | |
| Coating diameter | 245.0±10.0 | µm | |
| Coating-cladding concentricity error | ≤12.0 | µm | |
| Coating non-circularity | ≤6.0 | % | |
| Core-cladding concentricity error | ≤0.8 | µm | |
Cable construction:
1. G652D fiber 2. Resin 3. Filler fibers 4. Groove 5. HDPE sheath
Mechanical Performance (all optical measurements at 1300 nm and 850 nm)
| Test | Test Method |
| Tensile Performance | EN 187000 A1/ 501 IEC60 794-12-E1 |
| Tensile Service Load | |
| Flexing | IEC 60794-1-2-E11A |
| Crush I | IEC 60794-1-2-E3 |
| Crush II | IEC 60794-1-2-E3 |
Standard drum length
2000m/drum, 4000m/drum & 6000m/drum
Fiber color: (Support customized color)
| TIA/EIA 598 | No. | 1 | 2 | 3 | 4 | 5 | 6 |
| Color | Blue | Orange | Green | Brown | Grey | White |
Cable text print: (Support customized text)
HYOC FU 6F G652D [Drum No.] [Month-Year] [Meter marking]
Packing details:
| Fiber Count |
Length (m/drum) |
Packing size (mm) |
Gross weight (kg/drum) |
| 6 Fibers | 2000m/drum | 510*510*200mm | 9kg |
| 4000m/drum | 510*510*300mm | 12kg |
